Setting up a VoIP phone usually means connecting the handset to your business network, then having your provider activate and provision the service. Most businesses can use Ethernet, Wi-Fi or an adaptor, depending on the phone and the VoIP plan.
The physical setup is often simple:
If you are still comparing phone systems, start with VoIP phones for Australian businesses. This guide covers the practical wiring and connection questions that come next.
What devices do you need for VoIP?
You normally need an NBN internet service, a router, a VoIP phone or compatible old handset, and a VoIP service from a provider. You may also need an Ethernet cable, network switch, power adaptor or analogue telephone adaptor.
| Setup | Devices required | How the handset connects | Best suited to |
|---|---|---|---|
| IP desk phone | NBN service, router, IP phone, Ethernet cable | Ethernet to router or switch | Fixed office desks |
| Wi-Fi VoIP phone | NBN service, Wi-Fi router, Wi-Fi VoIP handset | Wi-Fi | Flexible desks or small offices |
| Old analogue phone | NBN service, router or ATA with a phone port, existing handset | Phone cable to ATA or router phone port | Reusing a suitable existing phone |
| Multiple office phones | NBN service, router, IP handsets, switch and power | Ethernet, Wi-Fi or both | Teams with several users |
| Softphone app | NBN service, computer or mobile, headset | Wi-Fi or mobile data | Remote and hybrid workers |
An IP phone is designed to connect directly to a network. It commonly uses an Ethernet cable and may receive power through that same cable. Some models also support Wi-Fi.
An analogue telephone adaptor, often called an ATA, allows a traditional phone to use a VoIP service. It converts the phone’s signal so it can communicate through your internet connection.
Your provider may supply the handset, adaptor and setup details. Some business services include either a physical handset or a softphone application, as shown in Nexgen’s Cloud Voice plan information (Nexgen Australia, 2023).
You do not usually need a separate NBN connection just for each phone. The phones share your business internet connection, although your network may need suitable capacity and configuration for the number of simultaneous calls.
For the difference between a hosted service, handsets and apps, see cloud VoIP for Australian businesses. The focus here is the physical connection.
How do you connect a VoIP phone to your router?
Connect one end of an Ethernet cable to the phone’s network port and the other end to a LAN port on your router or network switch. Then connect the handset to power, unless it is powered through Ethernet.
Look at the back of the phone for a port labelled Internet, LAN or, sometimes, a network symbol. Do not confuse this with the phone’s PC port. The PC port is designed to pass a computer’s network connection through the phone.
A typical single-phone setup looks like this:
“`text
NBN connection box or NBN wall socket
↓
Router
↓
Ethernet cable
↓
VoIP handset
“`
If your office has several phones, connect them to a network switch. The switch then connects back to the router. A business-grade switch may also provide Power over Ethernet, so compatible phones can receive power without a separate power adaptor.
Some IP phones have two network ports. You can connect the phone to the router, then connect a computer to the phone’s second port. This can reduce cabling at the desk, but the phone still needs to be configured correctly and the network must support the arrangement.
Your provider may need the phone’s MAC address, username, password or provisioning code. Do not guess these settings. VoIP registration details are provider-specific, and entering the wrong information can leave the phone showing “unregistered”.
For router-based VoIP services, the setup screens may include phone numbers, authentication details and phone-port settings. A TP-Link Australia VoIP router guide (TP-Link, 2022) shows the type of settings that may be required, although the exact fields differ between providers and router models.
How do you connect VoIP to the NBN?
Connect the NBN service to your compatible router first, then connect the VoIP phone to the router or business network. The phone does not normally plug directly into the NBN connection box.
The exact connection depends on your NBN technology.
With Fibre to the Premises, an NBN connection box normally presents an Ethernet service port. Your router connects to that port. Your VoIP handsets then connect to the router, switch or Wi-Fi network.
With Fibre to the Node or Fibre to the Building, the router may use the telephone wall socket and a VDSL connection. Your VoIP handset still connects to the router or network. It does not connect to the old telephone socket unless your provider has specifically designed the service that way.
With HFC, the router connects to the NBN cable connection box. The phone then connects to the router or network.
The important point is that your internet service and your phone service may come from different providers. Your NBN provider supplies the internet connection. Your VoIP provider supplies the phone number, call service and handset configuration.
The nbn VoIP phone setup guide (nbn, 2019) explains that a compatible phone may connect to the Wi-Fi gateway, while a traditional phone may need to connect to the gateway’s phone port or be replaced with a compatible device.
For a business, check these points before installation:
These questions prevent the most common mistake: buying handsets before confirming how the provider delivers the service.
Can you use your old landline phone for VoIP?
Yes, you can often use an old landline handset with VoIP, but it must connect through a compatible router phone port or an analogue telephone adaptor. Plugging it directly into a normal NBN wall socket will not usually make it work.
A basic old-phone setup looks like this:
“`text
NBN service
↓
Router or ATA
↓
Phone port
↓
Existing analogue handset
“`
The handset itself does not need to be branded as a VoIP phone if the ATA or router is handling the conversion. This can be useful if you have a reliable corded phone, a DECT cordless base station or a phone system that you are not ready to replace.
There are limits. Very old phones may use unusual wiring, require more power to ring, or have features that do not work properly with an ATA. Fax machines, alarms, EFTPOS equipment and other devices also need separate compatibility checks.
The nbn guide to traditional and VoIP-compatible phones (nbn, 2019) advises testing a traditional phone through the gateway’s phone port and checking with the phone and internet provider if it does not work.
For a business, an old handset may be fine for one basic line. It is less suitable when you need several extensions, call transfers, shared lines, call queues, headset support or central administration. In those cases, purpose-built business VoIP handsets are usually easier to manage.
Do not connect your old phone system to every wall socket without checking first. Internal phone cabling may need to be isolated from the incoming service, and additional cabling may require a registered cabler.
Do VoIP phones work over Wi-Fi?
Yes, Wi-Fi VoIP phones can work over a suitable wireless network. They need a compatible Wi-Fi connection, stable signal strength and enough network capacity to maintain clear calls.
Wi-Fi is useful when running Ethernet cable is difficult. It can also suit temporary work areas, meeting rooms, warehouses and businesses that move desks regularly.
| Connection type | Main advantage | Main limitation | Practical choice |
|---|---|---|---|
| Ethernet | Predictable connection and simple fault-finding | Requires cabling to each desk | Best default for fixed office phones |
| Wi-Fi | Flexible placement and less cabling | Signal and congestion can affect calls | Useful where cabling is difficult |
| Mobile softphone | Works away from the office | Depends on mobile data and device quality | Useful for remote staff |
| DECT cordless | Staff can move around the premises | Base station still needs a network connection | Useful for reception, retail and warehouses |
A Wi-Fi phone should be connected to the business wireless network, not an unsecured guest network. If staff use a mobile or desktop softphone, the same principle applies: the device needs a stable connection to the VoIP service.
Keep the phone close enough to an access point to maintain a strong signal. Large metal shelving, concrete walls and distance can create weak spots. If calls cut out when staff move around, the issue may be wireless coverage rather than the handset.
For fixed desks, Ethernet is usually the simpler choice because the cable carries both network traffic and, with compatible equipment, power. Wi-Fi can still be the right option when the office layout changes often.
If you are choosing between desk phones, cordless phones and apps, see best business phones or.
How do you set up a VoIP phone step by step?
Start with the internet connection, connect one phone, allow your provider to provision it, and test it before connecting the rest of the office. Setting up one handset first makes faults easier to identify.
1. Check the service details
Confirm that your NBN service is active and that your VoIP provider has supplied the number, handset and activation details. Ask whether the provider is provisioning the phone remotely or expects you to enter the settings yourself.
2. Set up the router
Connect the router to the NBN connection according to your NBN technology. Wait until the internet connection is working before troubleshooting the phone.
3. Connect one handset
Use Ethernet, Wi-Fi or an ATA, depending on the handset. Connect the power adaptor if required. Wait for the phone to start.
4. Check registration
The phone may display a registered, online or ready status. If it says unregistered, check the cable, internet connection and provider activation before changing advanced router settings.
5. Make test calls
Test an outgoing call, incoming call, voicemail and call transfer if your plan includes it. Check that the caller ID, handset volume and ring behaviour are correct.
6. Connect the remaining phones
Once the first handset works, connect the other phones one at a time. Label each handset and record which user or extension it belongs to.
7. Check the office network
During a busy period, test several calls at once. If voice quality drops when large files are uploaded or downloaded, ask your provider or IT support about network traffic management.
8. Record the final setup
Keep a simple record of the router, switch, phone locations, extension numbers and provider support details. This saves time when someone moves a desk or replaces a handset.
Some businesses self-install the cabling and plug-in equipment. Others have the provider provision the handsets and complete the configuration. The right option depends on the number of phones, your network and how much disruption your business can tolerate.
What should you check if your VoIP phone is not working?
Check power, the network cable, the router connection and the handset’s registration status before changing technical settings. Most setup faults are caused by a disconnected cable, incorrect port, missing activation or weak Wi-Fi signal.
Use this quick checklist:
| Problem | First check | Next step |
|---|---|---|
| Phone has no display | Power adaptor or PoE connection | Try another power source or switch port |
| Phone says unregistered | Provider activation and credentials | Ask the provider to check provisioning |
| No dial tone on old phone | Phone cable and ATA phone port | Confirm the VoIP service is active |
| Calls drop on Wi-Fi | Signal strength and distance | Test near the router or use Ethernet |
| One phone works, another does not | Extension assignment and cable | Connect the second phone to a known-working port |
| Poor audio quality | Network congestion and headset | Test another call and contact the provider |
Do not factory-reset a handset unless you know it can be provisioned again. A reset can remove the provider’s configuration and create more work.
Also check whether the problem affects one phone or the entire business. If every handset is offline, the issue is more likely to involve the router, NBN service, provider platform or power. If one phone is affected, start with that handset, cable or network port.
Will a VoIP phone work during a power outage?
Usually, no. A VoIP phone depends on powered equipment such as the NBN connection, router, switch, Wi-Fi access point or handset.
The nbn guidance on power blackouts (nbn, 2024) says equipment connected through the NBN network will not work during a power outage unless suitable backup arrangements are in place. A UPS may keep selected equipment running for a limited time, but it does not solve every network or mobile outage.
Your business continuity plan may include:
Emergency calling also needs attention. ACMA’s emergency calling guidance explains that certain VoIP services can call Triple Zero, but callers using VoIP may need to provide their town and state so emergency services can identify their location.
Ask your provider how emergency calling is handled, especially if phones are used at multiple sites or moved between offices.
Rather skip the wiring? Nexgen sets your VoIP phones up for you, including the practical connection and provisioning steps your business needs.
FAQ: how to set up a VoIP phone
How do I connect a VoIP phone to my router?
Connect the phone’s LAN or Internet port to a LAN port on your router or network switch using an Ethernet cable. Then connect power and wait for the provider to register the handset.
Can I use my old landline phone for VoIP?
Often, yes, if you connect it to a compatible router phone port or analogue telephone adaptor. Check compatibility first, especially if the phone is very old or has extra features.
Do VoIP phones work over Wi-Fi?
Yes, if the handset supports Wi-Fi and the wireless network is stable. Ethernet is usually the better choice for fixed office desks because it provides a more predictable connection.
How do I connect VoIP to the NBN?
Connect your router to the NBN service first, then connect the VoIP phone to the router, switch, Wi-Fi network or ATA. Your VoIP provider must then activate and configure the phone service.
